High Accuracy Assembly RTD Temperature Sensor + Transmitter PT100 to 4-20mA
To ensure we provide the most suitable temperature sensor for your application, please provide the following information:
1. Sensor Type: NTC Thermistor / RTD (PT100, PT1000) / Thermocouple / Digital (DS18B20)
2. Operating Temperature Range: e.g. -40°C to 125°C
3. Probe Structure & Material: Stainless steel, brass, plastic; dimensions (diameter & length)
4. Mounting Method: Thread size (M6, 1/4” NPT, G1/2”), flange or customized bracket
5. Cable Specifications: PVC, Teflon, Silicone, etc.; 2-wire, 3-wire, or 4-wire; length required
6. Environment: High humidity, corrosive, high-vibration, or standard indoor/outdoor
Frequently Asked Questions
Q1: What is the minimum order quantity (MOQ) for custom temperature sensors?
The MOQ typically depends on the type of sensor and customization requirements. For standard sensors like NTC and PT100, the MOQ is usually around 1000 pcs. For more complex custom sensors, the MOQ may be higher.
Q2: Can custom temperature sensors be adjusted for specific temperature ranges?
Yes, custom temperature sensors can be adjusted to meet your desired temperature range. Common ranges are typically from -20°C to +100°C, but for special requirements, PT100 and PT1000 sensors can be used for much higher or lower measurements.
Q3: Can I customize the wiring configuration for the temperature sensor?
Yes, the wiring configuration can be customized based on your needs, including the number of wires and sequence. For example, PT100 sensors can be configured as 2-wire, 3-wire, or 4-wire.
Q4: What is the typical lead time for custom temperature sensors?
The typical lead time is 3-4 weeks, depending on customization complexity and production volume. For urgent orders, expedited production can be arranged through discussion.
Q5: Can the shape and size of the sensor be customized?
Yes, the shape and size can be customized to fit your application. Different housing materials (stainless steel, brass, etc.), shapes, and sizes can be chosen to adapt to various installation requirements.
Q6: How are the performance and reliability of sensors verified?
Sensors are subjected to rigorous performance tests before delivery, including temperature-resistance characteristic testing, response time testing, and environmental durability testing to ensure reliability in the field.
